Not every RV is built the same — and neither is Titan Shield. Our Curv® composite panels are designed to be field-customizable, so you get a perfect fit regardless of your rig's layout.
Curv® Composite Technology
Titan Shield
Advanced RV Tire Blowout Protection
$199.00
$220.00
Complete kit — hardware included
Titan Shield is a lightweight Curv® composite panel system that mounts directly to your RV's underbelly — containing tire blowout damage before it reaches plumbing, wiring, or HVAC systems. Installs in minutes with a power drill. No welding. No professional install.
Curv® Certified
Free Shipping
Hardware Included
Made in USA
10-Minute Install Per Panel
No welding, cutting, or professional tools required. Just self-tapping stainless steel screws and a power drill.
Under 2 lbs Per Panel
70% lighter than steel guards with comparable impact absorption. Won't overload your axles.
-40°F to 300°F Operating Range
Curv® composite won't crack in winter, warp in summer, or rust — ever. Performs in any climate.
Field Customizable
Need a notch for a center support or crossmember? Titan Shield can be trimmed on-site with standard tools.
Choose Your Kit
What's In Each Kit
Every Titan Shield kit ships complete with Curv® composite panels and the self tapping fasteners needed for a 10-minute install.
Single Axle Kit
$199
Complete protection for single axle campers, pop-ups, and small travel trailers. One panel covers your wheel well.
Kit Includes:
- 2X Titan Shield (13.25" × 42") composite panels,
- Stainless steel self-tapping screws
- Installation guide
Panel Size:
13.25" × 42" (two panels)
Fits:
Single axle travel trailers, pop-up campers, small towables
Most Popular
Tandem Axle Kit
$299
Our most popular configuration. Full underbelly coverage between both wheel wells on a tandem axle rig.
Kit Includes:
- 4X Titan Shield (13.25" × 42") composite panels,
- Stainless steel self-tapping screws
- Installation guide
Panel Size:
13.25" × 42" (four panels)
Fits:
Tandem axle travel trailers, fifth wheels, toy haulers
Tri Axle Kit
$399
Maximum coverage for triple axle rigs. Two panels protect the full span between all three axles.
Kit Includes:
- 6X Titan Shield (13.25" × 42") composite panels,
- Stainless steel self-tapping screws
- Installation guide
Panel Size:
13.25" × 42" (six panels)
Fits:
Triple axle fifth wheels, large toy haulers, triple axle travel trailers
Need a custom fit? Some RVs have a center support or crossmember between the wheels. Titan Shield panels can be notched on-site with a jigsaw or circular saw to fit around any obstruction. Contact us if you're unsure about your fitment — we're happy to help.
Why Titan Shield?
Because Blowouts Shouldn't End Your Trip.
Every RV owner knows it's not if you'll have a blowout — it's when. Titan Shield transforms a potential disaster into a simple tire change.
The RV Blowout Problem
Tires are the #1 most common point of failure. A single blowout can cost $5,000–$15,000 in damage and sideline your rig for months.
Avoid Costly Repairs
Protect your underbelly, plumbing, electrical, and heating systems from catastrophic blowout damage.
70% Lighter Than Steel
Curv® composite delivers superior impact absorption without the weight penalty of metal alternatives.
10-Minute Install
Self-tapping stainless screws and pre-cut panels. No welding, cutting, or professional install needed.
All-Season Protection
Performs in extreme heat and cold. Won't rust, crack, or warp. Protects every mile, every season.
Installation
Installs in Minutes, Not Hours.
No welding. No professional installer. No special tools. Just a power drill and 10 minutes per panel.
Watch the full Titan Shield installation walkthrough
1
Clean the Mounting Area
Wipe down the underbelly area above your tires to remove road grime and debris. A clean surface ensures the best screw bite.
💡
A quick wipe with a damp rag is all you need — no solvents or prep chemicals required.
2
Position the Panel
Hold or clamp the Titan Shield panel against your RV's underbelly, centered above the tire(s). Ensure the panel covers the area most vulnerable to blowout debris.
💡
Having a second person hold the panel makes this easier, but it's doable solo with a couple of clamps.
3
Check for Obstructions
Look for center supports, crossmembers, wiring, or plumbing that may be in the way. If a support runs through the panel area, mark and notch the panel with a jigsaw or oscillating tool.
💡
Take a photo of the underside before you start — it helps with planning your panel placement.
4
Drive the Screws
Using the included stainless steel self-tapping screws, secure the panel to the underbelly frame. Start with the corners, then add screws every 8–10 inches along the edges.
💡
Don't overtighten — snug is enough. The Curv® material will flex and absorb impact better when not over-compressed.
5
Verify & Hit the Road
Give each screw a final check, ensure the panel is seated firmly with no rattles, and you're done. Repeat for each wheel position as needed.
💡
After your first drive, do a quick visual check to confirm everything stayed tight.
Tools You'll Need
Power Drill / Impact Driver
Cordless recommended
Tape Measure
To measure size
Marker / Pencil
For marking cut lines
Jigsaw / Circular saw
Only if notching needed
Questions about installation?
Our team is available to walk you through the install or help with custom fitment.
Custom Fitment
Built to Fit Your Rig.
Center Support? No Problem.
Many RVs have a center support or crossmember between the wheels. Titan Shield panels can be easily notched on-site using a jigsaw or oscillating multi-tool to fit around any obstruction — without compromising protection.
Field Trimmable
Cut and notch Titan Shield panels on-site with a jigsaw, oscillating tool, or circular saw. No special blades required.
Universal Mounting
Self-tapping stainless screws work with wood, aluminum, and composite underbelly materials. Fits most towable RV frame configurations.
Center Support Notching
RV has a crossmember between wheels? Simply measure, mark, and cut a notch. The remaining panel area still provides full blowout containment.
Fitment Support
Not sure if Titan Shield works with your specific rig? Send us your make, model, and year — we'll confirm fitment and recommend the right kit.
How We Compare
Titan Shield vs. The Competition
Feature
Titan Shield
Steel Guards
RettroBand
Fabric Wraps
Luan with Tape
.025 Aluminum
Material
Curv® Composite
14ga Steel
Polyurethane
Woven Fabric
Plywood w/woven tape
Aluminum
Weight
< 3 lbs/panel
25-33 lbs
15+ lbs
< 1 lb
5 lbs
5 lbs
Install Time
10 minutes
30-60 min
Professional
30 minutes
2 hours
2 hours
Price
$250 kit
$400-800/whl
$3,500-4,700
$30-50
$50
$325
Protection
★★★★★
★★★★☆
★★★★★
★☆☆☆☆
★★☆☆☆
★★★★☆
Corrosion Proof
Yes
No
Partial
N/A
No
No
DIY Install
Yes
Yes
No
Yes
No
Yes
Customizable
Field trimmable
No
No
No
Yes
Yes
The Technology
What is Curv®?
Curv® is an advanced self-reinforced polypropylene composite originally developed for automotive and aerospace. It absorbs and distributes impact energy rather than transferring it — making it the ideal material for vehicle protection.
Unlike steel or plastic alternatives, Curv® won't rust, won't crack in extreme cold, and won't warp in summer heat. And it's 100% recyclable.
Material
Curv® Self-Reinforced PP
Impact Strength
3-8X conventional PP
Weight
0.92 g/cm³
Chemical Resistance
Excellent
Temperature Range
-40°F to 300°F
Recyclable
100% Recyclable
Specifications
Technical Details
Material
Curv® Self-Reinforced Polypropylene
Panel Thickness
2mm Curv® sheet
Weight
< 3 lbs per panel
Single Axle Panel
13.25" × 48" (X 2)
Tandem Axle Panel
13.25" × 72" (X 2)
Tri Axle Panels
2X (13.25" × 48"), 2X (13.25 X 72")
Hardware
Stainless steel self-tapping screws
Temperature Range
-40°F to 300°F
Chemical Resistance
Fuel, oil, road salt, UV
Installation
Power drill only — 10min/panel
Field Customizable
Jigsaw / oscillating tool
Recyclable
100% recyclable
FAQ
Titan Shield Questions
Product & Fitment
Titan Shield is designed for most towable RVs — travel trailers, fifth wheels, toy haulers, and pop-up campers. We offer kits for single axle, tandem axle, and triple axle configurations. While kits are designed to work with most RV's, some trimming may be required to fit your model.
Yes. Titan Shield's composite material can be notched on-site with a jigsaw or multi-tool to fit around center supports, crossmembers, or other obstructions. The remaining panel area still provides full blowout containment.
Single Axle : One 13.25" × 42" panel — covers one wheel well (two provided).
Tandem Axle: Two 13.25" × 42" panels — cover the span between both wheels (four provided).
Tri Axle ($625): Three 13.25" × 42" panels — cover the span between all three axles (six provided)
Installation
Just a power drill or impact driver. All stainless steel self-tapping screws and a drill bit are included. If you need to notch around a center support, you'll also need a jigsaw or circular saw.
About 10 minutes per panel. A tandem axle setup takes roughly 10–15 minutes per side total including positioning and screw driving.
No. Titan Shield is designed as a true DIY product. If you can use a power drill, you can install Titan Shield. No welding, grinding, or cutting required (unless notching for a center support).
Material & Performance
Comparable impact protection at up to 70% less weight. Curv® won't rust, performs in extreme temperatures (-40°F to 300°F), and costs significantly less. Steel guards typically run $400–$1,400 per wheel and weigh 25–33 lbs each.
No. Curv® self-reinforced polypropylene is rated from -40°F to 300°F. It maintains its impact absorption and structural integrity across the full temperature range — summer highway heat and winter storage alike.
Yes. The Curv® composite in Titan Shield absorbs and distributes impact energy rather than transferring it. Originally developed for automotive and aerospace applications, it's engineered to contain high-velocity debris from tire failures and protect vulnerable underbelly systems.
Still have questions?
Contact Our Team →Don't Wait for a Blowout to Act.
Protect your RV, your vacation, and your wallet. Titan Shield installs in minutes and protects for years.
